*Images are for illustrative purposes. Actual product appearance and specifications may vary.
AcuSeek NEW HOT
add compare icon

DS-3E6603 LPU module, 24 Gigabit SFP Ports, 2 * 10GE SFP+ Ports

  • Supports 1000BASE Ethernet Optical Interface Module (SFP,LC)+2-Port 10G Ethernet Optical Interface Module(SFP+,LC)
View Less
View more
Data Sheet
Sales Inquiry

Available models:

DS-3E6600-48F2X-SA
View more View Less
DS-3E6600-48F2X-SA
Data Sheet

Specification

  • Hardware Specifications
  • Port48 × Gigabit SFP port,2 × 10 Gigabit SFP+ port
  • Switching CapacityPort Performance: 960 Gbps Whole-Device Performance: 1440 Gbps
  • Packet Forwarding RatePort Wire-Speed Packet Forwarding Rate: 714.24 Mpps Whole-Device Packet Forwarding Rate: 1071.36 Mpps
  • MAC Address Capacity32 K
  • Cache16 Mbits
  • Dimensions (W × H × D)436.60 mm × 40.60 mm × 210.00 mm (17.19'' × 1.60'' × 8.27'')
  • Net Weight2.105 kg (4.64 lb)
  • Gross Weight3.071 kg (6.77 lb)
  • Operating Temperature0°C to 50°C (32°F to 122°F)
  • Operating Humidity5% to 95% (no condensation)
  • Storage Temperature-40°C to 85°C (-40°F to 185°F)
  • Storage Humidity5% to 95% (no condensation)
  • Installation Mode1U Rack Mounting (19'' width)
  • Power Supply MethodDual Power Input,AC: 100~240 V, 50/60 Hz, 3.5~7 A
  • Surge Protection10 kV
  • Packing ListSwitch × 1 Regulatory Compliance and Safety Information × 1
  • Performance Specifications
  • Flash Memory256 MB
  • System Memory1 GB
  • MAC Address Capacity32 K
  • Jumbo Frame Size12000
  • VLANs4094
  • VLANIF Interfaces768
  • IPv4 Routes6144
  • IPv6 Routes2048
  • ARP Entries6144
  • System-wide L2 Multicast Entries1024
  • System-wide L3 Multicast Entries512
  • ACL Entries1024
  • QoS Forwarding Queues8
  • Service Features
  • Flow ControlSupported
  • Link AggregationSupports static aggregation. Supports dynamic aggregation via LACP.
  • Auto-NegotiationGigabit SFP ports 1 to 48: 1G/100M rate adaptation,10 Gigabit SFP+ ports 49 to 50: 10G/1G rate adaptation
  • VLANSupports 4K VLANs. Supports port-based VLAN. Supports IP subnet-based VLAN. Supports QinQ. Supports flexible QinQ. Supports Super VLAN.
  • MulticastSupports IGMPv1/v2/v3 Snooping.
  • STPSupports STP (IEEE 802.1d). Supports RSTP (IEEE 802.1w). Supports MSTP (IEEE 802.1s).
  • ERPSSupports G.8032 ERPS.
  • Private Loop DetectionSupported
  • Storm ControlSupported
  • Traffic SuppressionSupported
  • MirroringSupports local port mirroring. Supports N:1 port mirroring. Supports flow mirroring.
  • IPv4 ServiceSupports Ping. Supports Traceroute. Supports DNS. Supports ARP. Supports ARP Proxy.
  • IPv4 RoutingSupports static routing. Supports OSPFv2. Supports RIPv1/v2. Supports equal-cost multi-path (ECMP) routing. Supports policy-based routing (PBR). Supports VRRP.
  • IPv6 ServiceSupports Telnet6. Supports FTP6. Supports TFTP6. Supports Traceroute6. Supports Neighbor Discovery (ND). Supports Path MTU (PMTU) Discovery. Supports ICMPv6.
  • IPv6 RoutingSupports IPv6 static routing.
  • DHCPSupports DHCP Client. Supports DHCP Snooping. Supports DHCP Snooping Option 82/DHCP Relay Option 82. Supports DHCP Relay. Supports DHCP Server.
  • Cable DetectionSupports virtual cable test (VCT).
  • 802.1X AuthenticationSupported
  • MAC AuthenticationSupported
  • Portal AuthenticationSupported
  • RADIUSSupports RADIUS authentication.
  • ACLSupports L2 to L4 packet filtering. Supports ACL definitions based on source/destination MAC address, source/destination IP address, IP protocol type, TCP/UDP port number or port range, VLAN ID, etc. Supports Time Range-based ACLs. Supports ACL application globally, on ports, or to VLANs. Supports Basic ACL, Advanced ACL, and MAC ACL configurations. Supports inbound, outbound, and VLAN-based ACLs.
  • QoSSupports 802.1p/DSCP priority mapping. Supports queue scheduling mechanisms including SP, WRR, WFQ, SP+WRR, and SP+WFQ. Supports WRED. Supports priority marking and remarking. Supports flow-based packet filtering. Supports flow-based traffic statistics. Supports flow-based redirection. Supports flow-based rate limiting. Supports 8 queues per port.
  • SecuritySupports DoS attack protection. Supports CPU protection. Supports IP Source Guard. Supports port isolation. Supports HTTPS. Supports ARP detection. Supports ARP source suppression. Supports ARP attack protection. Supports IP-MAC binding. Supports port security.
  • LLDPSupports LLDP.
  • Operation Management
  • Topology DisplaySupported
  • Status AlarmSupported
  • Management PlatformSupports device management via web. Supports device management via iVMS-4200 Client. Supports SADP. Supports device management via Unified Network Management Platform.
  • SSHSupported
  • TelnetSupported
  • SNMPSupports SNMPv1. Supports SNMPv2c
  • Clock ManagementSupports NTP.
  • RMONSupported
  • sFlowSupports counter sampling.
  • FTPSupported
  • TFTPSupported
  • DDMFiber optical ports support DDM.
  • LogSupports system logs.
  • Approval
  • EMCCE-EMC (EN 55032: 2015+A11: 2020, EN IEC 61000-3-2: 2019, EN 61000-3-3: 2013+A1: 2019, EN 50130-4: 2011+A1: 2014, EN 55035: 2017+A11: 2020)
  • SafetyCB (IEC 62368-1: 2023, CE-LVD (EN 62368-1: 2024+A11: 2024)
  • ChemistryReach (Regulation (EC) No.1907/2006),WEEE (2012/19/EU),CE-RoHS (2011/65/EU)
*Product performance is based on testing in a controlled environment. Your results may vary due to several external and environmental factors.

Specification

Hardware Specifications
Port
48 × Gigabit SFP port,2 × 10 Gigabit SFP+ port
Switching Capacity
Port Performance: 960 Gbps Whole-Device Performance: 1440 Gbps
Packet Forwarding Rate
Port Wire-Speed Packet Forwarding Rate: 714.24 Mpps Whole-Device Packet Forwarding Rate: 1071.36 Mpps
MAC Address Capacity
32 K
Cache
16 Mbits
Dimensions (W × H × D)
436.60 mm × 40.60 mm × 210.00 mm (17.19'' × 1.60'' × 8.27'')
Net Weight
2.105 kg (4.64 lb)
Gross Weight
3.071 kg (6.77 lb)
Operating Temperature
0°C to 50°C (32°F to 122°F)
Operating Humidity
5% to 95% (no condensation)
Storage Temperature
-40°C to 85°C (-40°F to 185°F)
Storage Humidity
5% to 95% (no condensation)
Installation Mode
1U Rack Mounting (19'' width)
Power Supply Method
Dual Power Input,AC: 100~240 V, 50/60 Hz, 3.5~7 A
Surge Protection
10 kV
Packing List
Switch × 1 Regulatory Compliance and Safety Information × 1
Performance Specifications
Flash Memory
256 MB
System Memory
1 GB
MAC Address Capacity
32 K
Jumbo Frame Size
12000
VLANs
4094
VLANIF Interfaces
768
IPv4 Routes
6144
IPv6 Routes
2048
ARP Entries
6144
System-wide L2 Multicast Entries
1024
System-wide L3 Multicast Entries
512
ACL Entries
1024
QoS Forwarding Queues
8
Service Features
Flow Control
Supported
Link Aggregation
Supports static aggregation. Supports dynamic aggregation via LACP.
Auto-Negotiation
Gigabit SFP ports 1 to 48: 1G/100M rate adaptation,10 Gigabit SFP+ ports 49 to 50: 10G/1G rate adaptation
VLAN
Supports 4K VLANs. Supports port-based VLAN. Supports IP subnet-based VLAN. Supports QinQ. Supports flexible QinQ. Supports Super VLAN.
Multicast
Supports IGMPv1/v2/v3 Snooping.
STP
Supports STP (IEEE 802.1d). Supports RSTP (IEEE 802.1w). Supports MSTP (IEEE 802.1s).
ERPS
Supports G.8032 ERPS.
Private Loop Detection
Supported
Storm Control
Supported
Traffic Suppression
Supported
Mirroring
Supports local port mirroring. Supports N:1 port mirroring. Supports flow mirroring.
IPv4 Service
Supports Ping. Supports Traceroute. Supports DNS. Supports ARP. Supports ARP Proxy.
IPv4 Routing
Supports static routing. Supports OSPFv2. Supports RIPv1/v2. Supports equal-cost multi-path (ECMP) routing. Supports policy-based routing (PBR). Supports VRRP.
IPv6 Service
Supports Telnet6. Supports FTP6. Supports TFTP6. Supports Traceroute6. Supports Neighbor Discovery (ND). Supports Path MTU (PMTU) Discovery. Supports ICMPv6.
IPv6 Routing
Supports IPv6 static routing.
DHCP
Supports DHCP Client. Supports DHCP Snooping. Supports DHCP Snooping Option 82/DHCP Relay Option 82. Supports DHCP Relay. Supports DHCP Server.
Cable Detection
Supports virtual cable test (VCT).
802.1X Authentication
Supported
MAC Authentication
Supported
Portal Authentication
Supported
RADIUS
Supports RADIUS authentication.
ACL
Supports L2 to L4 packet filtering. Supports ACL definitions based on source/destination MAC address, source/destination IP address, IP protocol type, TCP/UDP port number or port range, VLAN ID, etc. Supports Time Range-based ACLs. Supports ACL application globally, on ports, or to VLANs. Supports Basic ACL, Advanced ACL, and MAC ACL configurations. Supports inbound, outbound, and VLAN-based ACLs.
QoS
Supports 802.1p/DSCP priority mapping. Supports queue scheduling mechanisms including SP, WRR, WFQ, SP+WRR, and SP+WFQ. Supports WRED. Supports priority marking and remarking. Supports flow-based packet filtering. Supports flow-based traffic statistics. Supports flow-based redirection. Supports flow-based rate limiting. Supports 8 queues per port.
Security
Supports DoS attack protection. Supports CPU protection. Supports IP Source Guard. Supports port isolation. Supports HTTPS. Supports ARP detection. Supports ARP source suppression. Supports ARP attack protection. Supports IP-MAC binding. Supports port security.
LLDP
Supports LLDP.
Operation Management
Topology Display
Supported
Status Alarm
Supported
Management Platform
Supports device management via web. Supports device management via iVMS-4200 Client. Supports SADP. Supports device management via Unified Network Management Platform.
SSH
Supported
Telnet
Supported
SNMP
Supports SNMPv1. Supports SNMPv2c
Clock Management
Supports NTP.
RMON
Supported
sFlow
Supports counter sampling.
FTP
Supported
TFTP
Supported
DDM
Fiber optical ports support DDM.
Log
Supports system logs.
Approval
EMC
CE-EMC (EN 55032: 2015+A11: 2020, EN IEC 61000-3-2: 2019, EN 61000-3-3: 2013+A1: 2019, EN 50130-4: 2011+A1: 2014, EN 55035: 2017+A11: 2020)
Safety
CB (IEC 62368-1: 2023, CE-LVD (EN 62368-1: 2024+A11: 2024)
Chemistry
Reach (Regulation (EC) No.1907/2006),WEEE (2012/19/EU),CE-RoHS (2011/65/EU)
For better user experience, we highly recommend you to update your device to the latest firmware asap.
