Analog Camera Input
8-ch BNC ports(1.0 Vp-p, 75 Ω), supporting HDTVI/CVI/AHD/CVBS auto-detect
IP Camera Input
Up to 16-ch of IP camera input,each up to 8MP
8-ch by default + 8-ch (analog channels are converted to IP channels)
Video Output
1-ch HDMI, 4K (3840 × 2160)/30Hz, 2K (2560 × 1440)/60Hz, 1920 × 1080/60Hz, 1280 × 1024/60Hz, 1280 × 720/60Hz;
1-ch VGA, 1920 × 1080/60Hz, 1280 × 1024/60Hz, 1280 × 720/60Hz
(HDMI/VGA simultaneous output);
1-ch CVBS (BNC, 1.0 Vp-p, 75 Ω), PAL: 704 × 576, NTSC: 704 × 480
Synchronous Playback
Up to 8-ch
HDTVI Input
8 MP(3840 × 2160)@12/15 fps,
3K(2960 x 1665)@25/20 fps,
3K(3328 x 1504)@20 fps,
2K(2304 x 1296)@20 fps,
5 MP(2560 × 1944)@20 fps,
4 MP(2560 × 1440)@25/30 fps,
1080P@25/30 fps,
720P@25/30 fps
AHD Input
5 MP(2560 × 1944)@20 fps,
4 MP(2560 × 1440)@25/30 fps,
1080P@25/30 fps,
720P@25/30 fps
HDCVI Input
8 MP(3840 × 2160)@12/15 fps,
3K(2880 × 1620)@20/25 fps,
5 MP(2592 × 1944)@20 fps,
4 MP(2560 × 1440)@25/30 fps,
1080P@25/30 fps,
720P@25/30 fps
Audio Input
1-ch RCA (2.0 Vp-p, 1 KΩ);
8-ch coaxial audio via BNC
Two-Way Audio
8-ch two-way audio via BNC ,
Support two-way audio from DVR local, web and Hik-Connect to analog camera;
Use the first RCA audio input if the two-way audio from DVR local to analog camera
